PK86X-PF
Inline High-Purity PFA Pressure Sensor
Product Description
The PK86X-PF flow-through pressure sensor is molded from high-purity PFA with no O-rings, preventing leakage and contamination while its straight-through liquid chamber eliminates dead zones for stable performance. The ceramic sensor measures acidic, alkaline, and ultra-pure liquids, with an optional sapphire version for HF/HCl, making it an excellent choice for high-purity liquid handling in semiconductor, photovoltaic, and display processes.
Product Description
-
ReliableHigh-purity PFA one-piece molded structure for enhanced safety and reliability -
RangeThe through-fow wetted chamber features a straight-through design, eliminat-ing dead zones -
Acid/AlkaliResistantThe sensor is ceramic,and a sapphire version is available for HF/HCl applica-tions -
ConnectionVarious connectiooptions in high-prity PFA materialare available
Technical Specifications
-
Application ScenariosGauge and vacuum liquid pressure measurement
-
Measurement Range-14.7...0...145psi
-
Accuracy Level (@ 25 ℃)±1%FS
-
Temperature Coefficient+0.1%FS/℃
-
Sensor MaterialCeramic/Sapphire
-
Overload Pressure1.5 × Rated Pressure (Maximum)
-
Medium Temperature0.....80°C
-
Ambient Temperature-10...65℃
-
Temperature Compensation Range0....40℃
-
Power Supply VoltageDC24V(10...30VDC)
-
Output Signal4...20mA、Digital Display 4-20mA+PNP/NPN*2
-
Connection MaterialPFA
-
Diaphragm MaterialPFA
-
Long-Term StabilityTypical value: ± 1% FS/Year
-
Process Connection TypeTube, Flared, or Beaded Connections
-
Protection GradeIP55
